Toggler BM5 Snaptoggle Plasterboard Fixing - Pkt/50

Stock Code: TOG25029

17 In Stock

£43.27 (exc VAT) per Each
£51.92 (inc VAT)

Quantity Ordered	Price per Each
1 - 4	£43.27 (exc VAT)
5+	£36.78 (exc VAT)

Quantity: - +

50 x BM5 (M5 thread) SNAPTOGGLE Fixings

Requires M5 Countersunk Machine Screws or M5 Panhead Machine Screws

Bolt Size: M5
Pack Size: 50
Ultimate Working Load (UWL) in 12.5mm Plasterboard: 108kg
Safe Working Load (SWL) in 12.5mm Plasterboard*: 27kg
Drill Hole Diameter: 13mm
Grip (Wall Thickness) Range: 9.5 - 92mm
Requires a Cavity of at least 48mm

* Multiple fixings can be used to increase the safe working load of what they will collectively hold. Note: This is dependent on the material they are being fixed to and the spacing of the fixings (eg. 2x fixings used in plasterboard right next to each other will not equal double the load as the same small area of plasterboard will have the entire load excerted on it).

The SNAPTOGGLE anchor is a heavy-duty hollow wall anchor for use in walls, ceilings, or floors of materials such as gypsum board, drywall with a wood or steel stud, concrete block, tile over drywall, wood, etc.

The anchor is pre-assembled and supplied ready for immediate use.

The ratcheting strap / locking cap assembly positions the strong one-piece zinc-plated (or stainless) steel anchoring channel on the rear of the wall, capturing it snugly and securely between the anchoring channel and the cap.

The remaining portion of the straps on the outside of the wall are then easily and quickly snapped off by hand at the required length, flush with the surface of the wall (no extra tools required). Holding is dependent only on a metal bolt to metal channel connection.

Save Time! So much quicker and easier to install than other comparable cavity wall fixings.
Exceptionally strong! Up to twice as strong as old fashioned wing toggles
Save Money! Turn a 2-person job into a 1-person job, and use shorter bolts
Corrosion Resistant! Longlife Gold plating and stainless steel versions available
Re-useable in the same hole! Remove the bolt without losing the anchor
Versatile! Works in both cavity and solid material up to 90mm (240mm Long anchor available)

NOTE: BM8 & BM10 SnapToggles require a 19mm hole.

Pack Quantity	50
Brand	TOGGLER
Thread Size	M5

Click on any of the following links to download the file.

TOGGLER Snaptoggle Technical Info (pdf)

Descriptions

50 x BM5 (M5 thread) SNAPTOGGLE Fixings

Requires M5 Countersunk Machine Screws or M5 Panhead Machine Screws

Bolt Size: M5
Pack Size: 50
Ultimate Working Load (UWL) in 12.5mm Plasterboard: 108kg
Safe Working Load (SWL) in 12.5mm Plasterboard*: 27kg
Drill Hole Diameter: 13mm
Grip (Wall Thickness) Range: 9.5 - 92mm
Requires a Cavity of at least 48mm

Save Time! So much quicker and easier to install than other comparable cavity wall fixings.
Exceptionally strong! Up to twice as strong as old fashioned wing toggles
Save Money! Turn a 2-person job into a 1-person job, and use shorter bolts
Corrosion Resistant! Longlife Gold plating and stainless steel versions available
Re-useable in the same hole! Remove the bolt without losing the anchor
Versatile! Works in both cavity and solid material up to 90mm (240mm Long anchor available)

NOTE: BM8 & BM10 SnapToggles require a 19mm hole.
